Memory module
Description Spare part number
1 GB, 1066 MHz DDR3 598859-001
2 GB, 1066 MHz DDR3 598856-001
4 GB, 1066 MHz DDR3 (for model 1.1 only) 599092-001
Before removing the memory module:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn on
the computer, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first disconnecting the power cord from the AC
outlet and then disconnecting the AC adapter from the computer.
4. Remove the battery (see
Battery on page 41).
Remove the memory module:
1. Turn the computer upside down with the front toward you.
2. Loosen the two Phillips PM2.5×6.0 captive screws (1) that secure the mini-card compartment
cover to the computer.
3. Lift the back side of the memory module cover (2)
4. Lift the cover off the computer (3). The mini-card compartment cover is included in the plastics
kit, spare part number 606006-001.
NOTE: Small tabs hold the cover in place. Firmly pull up on the cover to release the tabs.
5. Spread the retaining tabs (1) on each side of the memory module slot to release the memory
module. (The edge of the module opposite the slot rises away from the computer.)
50 Chapter 4 Removal and replacement procedures
