HP L2045W User Manual

Mounting Solutions
Removing the Monitor Pedestal Base
You can remove the monitor panel from the pedestal base to mount the panel on a wall, a swing
arm, or other mounting fixture.
CAUTION Before beginning to disassemble the monitor, be sure the monitor is turned off
and the power and signal cables are both disconnected. If the monitor has a connected audio
cable, disconnect it.
1. Disconnect and remove the signal and power cables from the back of the monitor.
2. Lay the monitor face down on a soft area to prevent it from getting scratched, defaced, or broken.
3. Remove the four screws that attach the pedestal base to the back of the monitor panel.
Figure 3-14 Removing the Monitor from the Pedestal Base
Mounting the Monitor
An optional HP Quick Release can be attached to the monitor panel. It allows you to quickly and
securely attach the monitor panel to the mounting fixture.
1. Remove the monitor panel from the pedestal base. Refer to
Removing the Monitor Pedestal
Base steps in the previous section.
14 Chapter 3 Setting Up the Monitor ENWW

HP L2045W Specifications

General

Pivot angle	0 - 90 °
Plug and Play	Yes
Tilt angle range	-5 - 30 °
Height adjustment	-
Panel mounting interface	100 x 100 mm
Pixel pitch	0.258 x 0.258 mm
Aspect ratio	16:10
Display diagonal	20.1 \
Display resolution	1680 x 1050 pixels
Vertical scan range	50 - 76 Hz
Horizontal scan range	24 - 93 kHz
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	60 W
Storage temperature (T-T)	-34 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Certification	Australian ACA Approval, Canadian Requirements/CSA, CE Marking, CISPR Requirements, Energy Star Compliant, German Ergonomic (TUV and GS Mark), ISO 9241-3, 7, 8 VDT Guidelines, ISO 13406-2 Pixel Defect Guidelines, MPR-II Compliant, PC2001 Certified, S. Korea
Product color	Silver
Country of origin	China
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	3

Weight and Dimensions

Depth (with stand)	223 mm
Width (with stand)	479 mm
Weight (with stand)	7800 g
Depth (without stand)	75 mm
Width (without stand)	315 mm
Height (without stand)	471 mm
Weight (without stand)	7680 g
