Entering User Modes
The video controller signal may occasionally call for a mode that is not preset if:
●
You are not using a standard graphics adapter.
●
You are not using a preset mode.
It this occurs, you may need to readjust the parameters of the monitor screen by using the on-screen
display or HP Display Assistant software. Your changes can be made to any or all of these modes
and saved in memory. The monitor automatically stores the new setting, then recognized the new
mode just as it does a preset mode. In addition to the 18 factory present modes for the L2045w
model, there are four user modes that can be entered and stored.
Energy Saver Feature
When the monitor is in its normal operating mode, the monitor uses less than 75 watts of power and
the Power light is green.
The monitor also supports a reduced power state. The reduced power state will be entered into if the
monitor detects the absence of either the horizontal sync signal and/or the vertical sync signal. Upon
detecting the absence of these signals, the monitor screen is blanked, the backlight is turned off, and
the power light is turned amber. When the monitor is in the reduced power state, the monitor will
utilize less than 2 watts of power. There is a brief warm up period before the monitor will return to its
normal operating mode.
Refer to the computer manual for instructions on setting energy saver features (sometimes called
power management features).
NOTE The above power saver feature only works when connected to computers that have
energy saver features.
By selecting the settings in the monitor's Energy Saver utility, you can also program the monitor to
enter into the reduced poser state at a predetermined time. When the monitor's Energy Saver utility
causes the monitor to enter the reduced power state, the power light blinks amber.
ENWW Entering User Modes 37
