HP L2045W User Manual

Front Panel Controls
Table 4-1 Monitor Front Panel Controls
Control Function
1 Menu/Select Opens, selects or exits the OSD menu.
2 − (Minus)/Auto
●
Navigates backward through the OSD menu and
decreases adjustment levels.
●
When the OSD menu is inactive, activates the auto
adjustment feature to optimize the screen image.
3 + (Plus) Navigates forward through the OSD menu and increases
adjustment levels.
4 Input Select Selects the video input (DVI-D or VGA)
5 Power LED Fully powered = Green.
Sleep mode = Amber.
Sleep Timer mode = Flashing Amber.
6 Power Turns the monitor on or off.
22 Chapter 4 Operating the Monitor ENWW

HP L2045W Specifications

General

Pivot angle	0 - 90 °
Plug and Play	Yes
Tilt angle range	-5 - 30 °
Height adjustment	-
Panel mounting interface	100 x 100 mm
Pixel pitch	0.258 x 0.258 mm
Aspect ratio	16:10
Display diagonal	20.1 \
Display resolution	1680 x 1050 pixels
Vertical scan range	50 - 76 Hz
Horizontal scan range	24 - 93 kHz
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	60 W
Storage temperature (T-T)	-34 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Certification	Australian ACA Approval, Canadian Requirements/CSA, CE Marking, CISPR Requirements, Energy Star Compliant, German Ergonomic (TUV and GS Mark), ISO 9241-3, 7, 8 VDT Guidelines, ISO 13406-2 Pixel Defect Guidelines, MPR-II Compliant, PC2001 Certified, S. Korea
Product color	Silver
Country of origin	China
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	3

Weight and Dimensions

Depth (with stand)	223 mm
Width (with stand)	479 mm
Weight (with stand)	7800 g
Depth (without stand)	75 mm
Width (without stand)	315 mm
Height (without stand)	471 mm
Weight (without stand)	7680 g
