NOTE You must set the current local time before you reset the time for Sleep Time or

On Time. Note that the time is displayed in a 24–hour clock format. For example, 1:15

p.m. is displayed as 13 hours 15 minutes.

5. Press the Menu button once to enter the adjustment mode for hours.

6. Press the − (Minus) or + (Plus) button to adjust the hour.

7. Press the Menu button again to enter the time for minutes.

8. Press the − (Minus) or + (Plus) button to adjust the minutes.

9. Press the Menu button to lock in the time chosen.

10. After setting the current time, the highlight automatically skips to Set Sleep Time hours. Repeat

steps 6 through 9 to set Sleep Time.

11. If you do not want to set Sleep Time, press the Menu button twice, then select Save and

Return to exit the menu.

12. After setting Sleep Time, the highlight automatically skips to Set On Time hours. Repeat steps

6 through 9 to set On Time.

13. Set the Timer mode to On to activate the Sleep Timer settings.

14. When you are finished, select Save and Return to exit the menu.

The fifth selection, Sleep Now, turns the monitor backlights off immediately and stays in sleep mode

until the next On Time activates or a monitor button is pressed.

HP Display LiteSaver

HP Display LiteSaver is a software application, available on the CD, that increases monitor life and

saves energy. It allows you to place the monitor into its low power sleep mode at predefined times by

shutting down or reducing power to most internal circuits. This helps protect the LCD panel against

image retention. Image retention can occur when the monitor is left on while displaying the same

image for an extended period of time, leaving a shadow of the image on the screen.

Installing the HP Display LiteSaver Software

1. Insert the CD in the computer CD-ROM Drive. The CD menu is displayed.

2. Select Install HP Display LiteSaver Software.

3. After installing the software, click the HP Display LiteSaver icon in the Windows system tray or

right-click the icon and select Configure from the pop-up menu.

4. Select the following options to configure the HP Display LiteSaver features:

Table 4-3 HP Display LiteSaver Configuration Options

Select This Option To Do This

Enable Display LiteSaver Enables the HP Display LiteSaver functions; deselect to disable the HP Display

LiteSaver

30 Chapter 4 Operating the Monitor ENWW

Questions and Answers:

Need help?

Do you have a question about the HP L2045W and is the answer not in the manual?

HP L2045W Specifications

General

Pivot angle	0 - 90 °
Plug and Play	Yes
Tilt angle range	-5 - 30 °
Height adjustment	-
Panel mounting interface	100 x 100 mm
Pixel pitch	0.258 x 0.258 mm
Aspect ratio	16:10
Display diagonal	20.1 \
Display resolution	1680 x 1050 pixels
Vertical scan range	50 - 76 Hz
Horizontal scan range	24 - 93 kHz
Contrast ratio (typical)	800:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	60 W
Storage temperature (T-T)	-34 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Certification	Australian ACA Approval, Canadian Requirements/CSA, CE Marking, CISPR Requirements, Energy Star Compliant, German Ergonomic (TUV and GS Mark), ISO 9241-3, 7, 8 VDT Guidelines, ISO 13406-2 Pixel Defect Guidelines, MPR-II Compliant, PC2001 Certified, S. Korea
Product color	Silver
Country of origin	China
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	3
