Hard drive
NOTE: The hard drive spare part kit does not include the hard drive cable, or hard drive bracket and
screws.
Description Spare part number
9.5 mm (0.37 in) × 6.35 cm (2.50 in) SATA
1 TB, 5400 rpm 676521-005
750 GB, 7200 rpm 633252-005
750 GB, 5400 rpm 634250-005
640 GB, 5400 rpm 669300-005
500 GB, 7200 rpm 634925-005
500 GB, 5400 rpm 669299-005
320 GB, 5400 rpm 622643-005
Hard Drive Hardware Kit (includes hard drive cable, and hard drive bracket and screws)
701945-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement.
Before removing the hard drive, follow these steps:
1.
Shut down the computer.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 42).
5.
Remove the keyboard (see
Keyboard on page 47).
6.
Remove the top cover (see
Top cover on page 51).
56 Chapter 4 Removal and replacement procedures
