WLAN module
Description Spare part number
Intel Centrino Wireless-N 2230 802.11 b/g/n 2×2 WiFi and Bluetooth 4.0 combination
adapter, for use with computers with Intel processors
670290-005
Qualcomm Atheros AR9485 802.11 b/g/n 1×1 WiFi Adapter
675794-005
[Author note:]mango
Qualcomm Atheros AR9565 802.11 b/g/n 1×1 WiFi and Bluetooth 4.0 Combo Adapter for
use with computers with Intel processors, not supported on Ubuntu Linux, (select models only)
690019-005
[Author note:]ROMA
Ralink RT3290LE 802.11 b/g/n 1x1 WiFi and Bluetooth 4.0 Combo Adapter (select models
only)
690020-005
[Author note:]flamingo2
Ralink RT5390R 802.11 b/g/n 1×1 WiFi Adapter (select models only)
691415-005
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement.
CAUTION: To prevent an unresponsive system, replace the wireless module only with a wireless
module authorized for use in the computer by the governmental agency that regulates wireless devices
in your country or region. If you replace the module and then receive a warning message, remove
the module to restore device functionality, and then contact technical support.
Before removing the WLAN module, follow these steps:
1.
Shut down the computer.
2.
Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 42).
5.
Remove the keyboard (see
Keyboard on page 47).
6.
Remove the top cover (see
Top cover on page 51).
60 Chapter 4 Removal and replacement procedures
