HP Pavilion 15 Sleekbook User Manual

10.
Remove the WLAN (see
WLAN module on page 60).
11.
Remove the system board (see
System board on page 63).
Remove the display assembly.
CAUTION: Support the display assembly when removing the following screws. Failure to support
the display assembly can result in damage to the display assembly and other computer components.
▲
Remove the four Phillips screws from the display hinges (1) and lift the display assembly (2).
Reverse this procedure to reinstall the display assembly.
For instructions on removing the display assembly components for a TouchSmart Display, continue to
the next section.
Display assembly components
Description Spare part number
Antenna Kit (includes left and right wireless antenna cables and transceivers)
701676-001
Display Panel Cable Kit (includes display panel cable and webcam/microphone module cable)
701681-001
Display back cover enclosure:
84 Chapter 4 Removal and replacement procedures

HP Pavilion 15 Sleekbook Specifications

General

Display Size	15.6 inches
Resolution	1366 x 768
RAM	Up to 8GB
Storage	500GB / 750GB HDD
Graphics	Integrated Intel HD Graphics
Operating System	Windows 8
Battery	4-cell Lithium-ion
Wireless	802.11b/g/n
Ports	2 x USB 3.0, 1 x USB 2.0, HDMI, RJ-45, Headphone/Microphone Combo Jack
