HP ProBook 440 G1 User Manual

15 Statement of Volatility
The purpose of this document is to provide general information regarding non-volatile memory in
industry-standards based HP Business Notebook PC systems and provide general instructions for
restoring nonvolatile memory that can contain personal data after the system has been powered off and
the hard drive has been removed.
HP Business Notebook PC products that use Intel®-based or AMD®-based system boards contain
volatile DDR memory. The amount of nonvolatile memory present in the system depends upon the
system configuration. Intel-based and AMD-based system boards contain nonvolatile memory
subcomponents as originally shipped from HP assuming that no subsequent modifications have been
made to the system and assuming that no applications, features, or functionality have been added to or
installed on the system.
Following system shutdown and removal of all power sources from an HP Business Notebook PC
system, personal data can remain on volatile system memory (DIMMs) for a finite period of time and
will also remain in nonvolatile memory. The steps below will remove personal data from the notebook
PC, including the nonvolatile memory found in Intel-based and AMD-based system boards. Some of
these steps are disclosed in the Maintenance & Service Guides available for HP PC products available
on the product support pages at
www.hp.com.
1. Follow steps (a) through (I) below to restore the nonvolatile memory that can contain personal
data. Restoring or reprogramming nonvolatile memory that does not store personal data is neither
necessary nor recommended.
a. Enter BIOS (F10) Setup by powering on the system and pressing F10 when prompted near
the bottom of the display, or press the ESC key to display the start up menu, then press F10 .
If the system has a BIOS administrator password, enter the password at the prompt.
b. Select the File menu, then Restore Defaults.
c. Select the System Configuration menu, then Restore Security Defaults.
d. If an asset or ownership tag is set, select the Security menu and scroll down to the Utilities
menu. Select System IDs, and then select the tag that has been set. Press the spacebar
once to clear the tag, then press Enter to return to the prior menu.
e. If a DriveLock password is set, select the Security menu, select Hard Drive Tools, scroll
down to DriveLock, then select DriveLock password. Select the desired hard drive.
Click Disable protection, enter the existing master DriveLock password, then press Enter to
confirm and return to the prior menu. Repeat this procedure if more than one hard drive has
a DriveLock password.
f. If an Automatic DriveLock password is set, select the Security menu, select Hard Drive
Tools, scroll down to Automatic DriveLock, then select the desired hard drive and
disable protection. Repeat this procedure if more than one hard drive has an Automatic
DriveLock password.
g. Select the File menu, then Reset BIOS Security to factory default. Click yes at the
warning message.
h. Select the File menu, then Save Changes and Exit.
128 Chapter 15 Statement of Volatility

HP ProBook 440 G1 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Country of origin	China
Bus type	DMI
Stepping	C0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4200 Mobile series
Processor socket	PGA946
Processor threads	4
Processor codename	Haswell
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	37 W
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® HM87
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 4 GB
LightScribe	-
AC adapter included	Yes
Intel segment tagging	Enterprise, Professional
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Total storage capacity	750 GB
Compatible memory cards	Memory Stick (MS), MSXC, SD, SDHC, SDXC
Number of HDDs installed	1
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x416
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4600
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Audio system	DTS Sound+
Front camera resolution	1280 x 720 pixels
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI version	1.4a
Charging port type	DC-in jack
DisplayPorts quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pointing device	Touchpad
Bundled software	HP Wireless Hotspot\\r HP Mobile Connect\\r HP ePrint, SMS Roaming Alert\\r HP Recovery Manager
Operating system installed	Windows 8
Processor code	SR1HA
Processor ARK ID	76348
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 x 4.7 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Battery capacity	47 Wh
Battery life (max)	9.15 h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	238.5 mm
Width	339.2 mm
Weight	2100 g
Height (front)	22.4 mm
