HP ProBook 440 G1 User Manual

System board
NOTE: All system board spare part kits include replacement thermal material.
Description Spare part number
Models without Windows 8 with 1-GB of discrete graphics memory 734083-001
Models without Windows 8 with 2-GB of discrete graphics memory 734084-001
Models without Windows 8, with UMA graphics, without WWAN 734085-001
Models without Windows 8, with UMA graphics, with WWAN 734087-001
Windows 8 Standard models with 1-GB of discrete graphics memory 734083-501
Windows 8 Professional models with 1-GB of discrete graphics memory 734083-601
Windows 8 Standard models with 2-GB of discrete graphics memory 734084-501
Windows 8 Professional models with 2-GB of discrete graphics memory 734084-601
Windows 8 Standard models, UMA graphics, without WWAN 734085-501
Windows 8 Professional models, UMA graphics, without WWAN 734085-601
Windows 8 Standard models, UMA graphics, with WWAN 734087-501
Windows 8 Professional models, UMA graphics, with WWAN 734087-601
Before removing the system board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet,
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 37).
5. Remove the following components:
a. Service door (see
Service door on page 38).
b. Hard drive (see
Hard drive on page 39)
c. Optical drive (see
Optical drive on page 42)
d. Keyboard (see
Keyboard on page 50)
e. Top cover (see
Top cover on page 54)
When replacing the system board, be sure to remove the following components from the defective
system board and install on the replacement system board:
●
Memory module (see
Memory modules on page 44)
●
WLAN/Bluetooth module (see
WLAN/Bluetooth combo card on page 46)
68 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

HP ProBook 440 G1 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black, Silver
Country of origin	China
Bus type	DMI
Stepping	C0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-4200 Mobile series
Processor socket	PGA946
Processor threads	4
Processor codename	Haswell
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	37 W
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® HM87
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 4 GB
LightScribe	-
AC adapter included	Yes
Intel segment tagging	Enterprise, Professional
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Total storage capacity	750 GB
Compatible memory cards	Memory Stick (MS), MSXC, SD, SDHC, SDXC
Number of HDDs installed	1
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x416
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4600
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Audio system	DTS Sound+
Front camera resolution	1280 x 720 pixels
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDMI version	1.4a
Charging port type	DC-in jack
DisplayPorts quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Pointing device	Touchpad
Bundled software	HP Wireless Hotspot\\r HP Mobile Connect\\r HP ePrint, SMS Roaming Alert\\r HP Recovery Manager
Operating system installed	Windows 8
Processor code	SR1HA
Processor ARK ID	76348
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 x 4.7 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Battery capacity	47 Wh
Battery life (max)	9.15 h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	238.5 mm
Width	339.2 mm
Weight	2100 g
Height (front)	22.4 mm
