Table 3-2 Display component descriptions and part numbers (continued)
Item Component Spare part number
(3) Display panel (includes display panel adhesive and bezel adhesive)
FHD, privacy, 1000 nits M47420-001
FHD, 400 nits M47418-001
FHD, 400 nits, locked M49788-001
HD, SVA, 250 nits M47419-001
FHD, UWVA, 250 nits M47417-001
FHD, UWVA, 250 nits, locked M49787-001
(4) Hinges (left and right; includes bezel trim pieces, bezel trim protective shielding, display panel
adhesive, and bezel adhesive)
M21732-001
(5) WLAN antennas and cables (includes display panel adhesive and bezel adhesive) M21727-001
(6) Display/camera cable (includes display panel adhesive and bezel adhesive) M47416-001
(7) Display back cover (includes bezel adhesive)
Models with a 250 nit display panel M21987-001
Models with a 400 nit display panel M21989-001
Cable Kit
To identify the contents of the Cable Kit, use this table.
Table 3-3 Cable Kit content descriptions and part number
Component Spare part number
Cable Kit, includes: M21713-001
I/O board cable
I/O board cable (USB 3.0)
Touchpad cable
Fingerprint reader board cable
Miscellaneous parts
To identify the miscellaneous parts, use this table.
Table 3-4 Miscellaneous part descriptions and part numbers
Component Spare part number
AC adapters
65 W, nPFC, SMART, 4.5 mm, EM 913691-850
65 W, nPFC, SMART, 3 pin, 4.5 mm 710412-001
22 Chapter 3 Illustrated parts catalog
