A-1
A
Specifications
Switch Specifications
Physical
Electrical
The switch automatically adjusts to any voltage between 100-127 and 200-240
volts and either 50 or 60 Hz.
Environmental
Safety
Complies with:
■ EN60950-1 / IEC 60950-1
■ CSA 22.2 No. 60950-1
■ UL 60950-1
Width: 44 cm (17.42 in)
Depth: 17 cm (6.74 in)
Height: 4.4 cm (1.73 in)
Weight: 1.97 kg (4.32 lbs)
AC voltage: 100-127 volts, 200-240 volts
Maximum current: 0.75 A (100-127 V), 0.4 A (200-240 V)
Frequency range: 50/60 Hz
Operating Non-Operating
Temperature: 0 °C to 40 °C (32 °F to 104 °F) -40 °C to 70 °C (-40 °F to 158 °F)
Relative humidity:
(non-condensing)
15% to 95% at 40 °C (104 °F) 15% to 90% at 65 °C (149 °F)
Maximum altitude: 3048 m (10,000 ft) 3048 m (10,000 ft)
