B-27
Monitoring and Analyzing Switch Operation
Port and Static Trunk Monitoring Features
Configuring the Monitor Port. This command assigns or removes a mon-
itoring port, and must be executed from the global configuration level. Remov-
ing the monitor port disables port monitoring and resets the monitoring
parameters to their factory-default settings.
Syntax: [no] mirror-port [< port-num >]
For example, to assign port A6 as the monitoring port:
ProCurve(config)# mirror-port a6
To turn off monitoring:
ProCurve(config)# no mirror-port
Selecting or Removing Ports and Static Trunks As Monitoring
Sources. After you configure a monitor port you can use either the global
configuration level or the interface context level to select ports and static
trunks as monitoring sources. You can also use either level to remove moni-
toring sources.
Syntax: [no] interface ethernet < monitor-list > monitor
where: < monitor-list > includes port numbers and static trunk names
such as a4, c7, b5-b8, and trk1.
Elements in the monitor list can include port numbers and static trunk names
at the same time.
For example, with a port such as port A6 configured as the monitoring (mirror)
port, you would use either of the following commands to select these ports
and static trunks for monitoring:
• A1 through A3, and A5
• Trunks 1 and 2
Figure B-22. Examples of Selecting Ports and Static Trunks as Monitoring Sources
From the global
config level,
selects ports
and trunks for
monitoring
sources.
Selects the interface context level, then
selects the ports as monitoring sources.
