5-1
Planning and
Implementation for the 2610-
PWR Switches
5
Planning and Implementation for the
2610-PWR Switches
This chapter discusses the planning process a user should follow to
successfully implement a PoE 2610-PWR Switches. The 2610-PWR switches
and the 2600-PWR switches utilize a common PoE implementation. Port
counts, power supply wattages, specifications, and functionality for these two
platforms are the same with respect to PoE.
After understanding what PoE is and its operating rules, the next step to
implementation is planning. See “General Considerations” page A-1, for an
example list of considerations during the planning phase.
Planning Your PoE Configuration
This section assists you in building a reliable and, if required, redundant PoE
configuration. Using the following examples you can plan, build, and connect
your PoE devices quickly and easily.
Your configuration may vary however this section discusses some of the more
common configurations.
There are three configurations:
■ ProCurve 2610-24/12PWR Switch
■ ProCurve 2610-24-PWR Switch
■ ProCurve 2610-48-PWR Switch
Each example shows a complete configuration including an optional 600 RPS/
EPS or 610 EPS unit. A table shows the PoE power available to connected PoE
devices when using just the switch or when using the switch and either the
600 RPS/EPS or 610 EPS unit. The tables show the available power when the
600 RPS/EPS or 610 EPS unit is providing PoE power to connected switch
devices.
