Installing the GL Modules

Overview

You can install any of the GL modules into any of the HP Procurve switches

that have a compatible module slot. As of this printing, those are the HP

Procurve Series 4100GL Switches:



4108GL (p/n J4865A)



4108GL Bundle (p/n J4861A)



4104GL (p/n J4887A)



4148GL (p/n J4888A) -- a 4104GL bundle

You can install the modules into the switch either with the switch powered on

or off. The following procedures assume the switch is powered on.

1. Install the modules in a switch slot (see page 5).

If you have installed any modules into slots that were previously occupied

by a different type module, the status LED for the slot will be flashing

indicating that you must reset the switch (see page 15).

2. If you are using the Gigabit Transceiver GL Module or the mini-GBIC GL

Module, you can install the transceivers or mini-GBICs in the appropriate

module before or after installing that module into the switch.

Note The HP Procurve transceivers and mini-GBICs can be “hot swapped”. That is,

they can be installed or removed after the GL Module is installed in the switch

and receiving power.

Please see the Installation Guide that came with the transceivers for more

information on installing the transceivers. The information for using the

mini-GBICs is included in this manual (see page 7).

3. Verify that the modules are installed correctly (see page 8).

4. Connect the network cabling (see page 9).

5. Optionally, customize the configuration for the modules’ ports (unless the

default port configuration is satisfactory for your network application -

see page 13).

Note If necessary, you can “hot-swap” one module for another; that is, replace one

module with another while the switch is still powered on, without interrupting

the operation of the rest of the switch ports. For more information, see page 14.
