HP ProCurve Installation Guide

2
Features
Contact your HP-authorized networking products reseller or your HP repre-
sentative for information on availability of other modules, transceivers, and
mini-GBICs. You can also visit the HP networking products Web site at http:/
/www.hp.com/go/hpprocurve to get more information.
Features
Example: The HP Procurve 24-Port 10/100-TX GL Module
The HP Procurve Switch GL Modules have the following features:
 auto-enabled ports—the ports are all configured to be ready for network
operation as soon as a viable network cable is connected.
 auto-configuration—a default configuration is applied to the module
when the switch is powered on and the module passes self test; this default
configuration works well for most network installations.
 LEDs that provide information on the link status, network activity,
connection bandwidth, and communication mode (half or full duplex).
 “hot swap modules” operation—you can add a module or replace a
module without having to shut down the switch (changing the module
type in a given slot does require a switch reset).
 “hot swap transceivers” operation—you can add, replace, or change the
type of any of the transceivers and mini-GBICs that you use in the Gigabit
Transceiver GL Module and mini-GBIC GL Module, without having to first
remove the module, and without having to shut down the switch.
24
18
23
17
22
16
21
15
19
13
20
14
7
Link|Mode
Link|Mode
1
8
2
9
3
10
4
11
5
12
6
7
12 19 24
181
hp procurve
gl module
10/100-TX
J4862B
10/100-TX Ports (1-24) all ports are HP Auto-MDIX
gl
module
retaining screw
network ports
Link and Mode LEDs
(one pair per port)
3013_ed2.book Page 2 Friday, August 9, 2002 2:02 PM
