HP ProDesk 400 G3 Small Form Factor User Manual

Access panel
1. Prepare the computer for disassembly (Preparation for disassembly on page 17).
2. Loosen the thumbscrew on the rear of the computer (1) then slide the panel back (2) and lift if o the
computer (3).
To install the access panel, reverse the removal procedure.
Front bezel
1. Prepare the computer for disassembly (Preparation for disassembly on page 17).
2. Remove the access panel (Access panel on page 18).
3. Lift up the three tabs on the top side of the bezel (1), and then rotate the bezel o the chassis (2).
NOTE: You may need a tool to pry up the three bezel tabs, or you can remove the hard drive cage to
make the tabs easier to access.
To install the front bezel, reverse the removal procedure.
18 Chapter 4 Removal and replacement procedures: Small Form Factor

HP ProDesk 400 G3 Small Form Factor Specifications

General

Brand	HP
Model	ProDesk 400 G3 Small Form Factor
Category	Desktop
Language	English
