Misc boards
Description Spare part number
nVidia Quadro NVS310 PCIe x16 graphics card, 512 MB 707252-001
nVidia Quadro NVS315 PCIe x16 graphics card, 1 GB 720837-001
AMD Radeon HD8490 PCIe x16 graphics card, 1 GB 717219-001
AMD Radeon HD8470 PCIe x16 graphics card, 2 GB (for use only in China) 729085-001
AMD Radeon HD8350 DH PCIe x16 graphics card, 1 GB DDR3 717220-001
AMD Radeon HD8350 PCIe x16 graphics card, 1 GB DDR3 (for use only in China) 729084-001
GeForce GT630 PCIe x16 graphics card, 2 GB 702084-001
Intel PRO/1000 single port GbE NIC, includes bracket 728562-001
HP WLAN 802.11 a/b/g/n 2x2 PCIe module 695915-001
HP WLAN/Bluetooth module 733687-001
Sequential part number listing
Spare part
number
Description
336445-001 Chassis foot (package of four (4) oval shaped rubber-adhesive backed pads)
397117-001 Hard drive conversion bracket
450712-001 Hard drive grommet for use on 3.5-inch drives
463023-001 DMS-59 to dual VGA cable
487562-001 DisplayPort cable
583345-001 WLAN antennas
586721-001 Adapter, 2.5-inch hard drive
594220-001 Hard drive grommet for use on 2.5-inch drives
608394-001 DVD-ROM drive
613202-001 1 TB, 7200 rpm hard drive
613208-001 500 GB, 7200 rpm SATA hard drive
616608-001 2 TB, 7200 rpm SATA hard drive
617450-001 Adapter, DisplayPort to HDMI
632484-001 Adapter, DisplayPort to VGA
636922-001 Rear chassis fan
638815-001 Serial port PCI card
16 Chapter 3 Illustrated parts catalog
