Front bezel security
The front bezel can be secured in place by installing a screw through the front of the chassis into the front
bezel.
1. Prepare the computer for disassembly (Preparation for disassembly on page 19)
2. Remove the access panel (Access panel on page 20)
3. Install a 6-32 screw through the front of the chassis and into the screw hole located below the center
bezel release tab.
4. Replace the computer access panel.
5. Reconnect the power cord and any external devices, and then turn on the computer.
6. Lock any security devices that were disengaged when the access panel was removed.
22 Chapter 4 Removal and replacement procedures – Microtower (MT) chassis
