HP ProLiant ML10 v2 User Manual

Software and configuration utilities 43
Software and configuration utilities
Server mode
The software and configuration utilities presented in this section operate in online mode, offline mode, or in
both modes.
Software or configuration utility Server mode
HP iLO (on page 43)
Online and Offline
Integrated Management Log (on page 44)
Online and Offline
HP Insight Remote Support (on page 44)
Online
HP Insight Online (on page 45)
Online
HP Insight Diagnostics (on page 45)
Online
Scripting Toolkit for Windows and Linux (on page 46)
Online
HP Service Pack for ProLiant (on page 46)
Online and Offline
HP Smart Update Manager (on page 46)
Online and Offline
HP Smart Storage Administrator (on page 47)
Online and Offline
Product QuickSpecs
For more information about product features, specifications, options, configurations, and compatibility, see
the product QuickSpecs on the HP website (http://www.hp.com/go/qs).
HP iLO
The iLO subsystem is a standard component of HP ProLiant servers that simplifies initial server setup, server
health monitoring, power and thermal optimization, and remote server administration. The iLO subsystem
includes an intelligent microprocessor, and secure memory. This design makes iLO independent of the host
server and its operating system.
iLO features Agentless Management. All key internal subsystems are monitored by iLO. If enabled, SNMP
alerts are sent directly by iLO regardless of the host operating system or even if no host operating system is
installed.
Embedded remote support software is available on HP ProLiant Gen8 and later servers with iLO, regardless
of the operating system software and without installing OS agents on the server.
Using iLO, you can do the following:
• Access a high-performance and secure Integrated Remote Console to the server from anywhere in the
world if you have a network connection to the server.
• Use the shared .NET Integrated Remote Console to collaborate with up to four server administrators.
• Remotely mount high-performance Virtual Media devices to the server.

HP ProLiant ML10 v2 Specifications

General

Bus type	DMI
Stepping	C0
FSB Parity	No
Scalability	1S
Processor cache	8 MB
Processor cores	4
Processor model	E3-1220V3
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200 v3
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Motherboard chipset	Intel® C222
Processor frequency	3.1 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor front side bus	- MHz
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x8, 1x16, 2x4, 2x8
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
Thermal solution specification	PCG 2013D
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
HDD size	3.5 \
HDD interface	-
SSD interface	Serial Attached SCSI (SAS)
Total storage capacity	1000 GB
Maximum storage capacity	24 TB
Memory slots	4x DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Graphics card	G200
DVD interface type	SATA
Graphics card family	Matrox
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Serial ports quantity	0
USB 2.0 ports quantity	2
PCI Express slots version	3.0
Performance management	HP iLO
Compatible operating systems	Microsoft Windows Server\\r Canonical Ubuntu\\r Red Hat Enterprise Linux (RHEL)\\r SUSE Linux Enterprise Server (SLES)\\r VMware
Processor ARK ID	75052
Intel Identity Protection Technology version	1.00
Chassis type	Tower (4U)
Power supply	350 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 9144 m
Storage temperature (T-T)	-30 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	10 - 90 %
On-board graphics card model	Not available

Weight and Dimensions

Depth	475.2 mm
Width	175 mm
Height	368.2 mm
