NOTE: The thermal material must be thoroughly cleaned from the surfaces of the heat sink and the system

board components each time the heat sink is removed. Replacement thermal material is included with the heat

sink and system board spare part kits.

Thermal paste is used on the processor (1) and the heat sink section (2) that services it.

Reverse this procedure to install the heat sink.

Keyboard

NOTE: All keyboard spare part kits include the backlight cover, backlight cable, and keyboard cable.

For use in country/region Spare part number For use in country/region Spare part number

In ceramic white nish: For use in Russia L04544-251

For use in Canada L04544-DB1 For use in Saudi Arabia L04544-171

For use in the Czech Republic

and Slovakia

L04544-FL1 For use in South Korea L04544-AD1

For use in Denmark, Finland,

and Norway

L04544-DH1 For use in Spain L04544-071

For use in France L04544-051 For use in Switzerland L04544-BG1

For use in Germany L04544-041 For use in Taiwan L04544-AB1

For use in Japan L04544-291 For use in Thailand L04544-281

For use in Latin America L04544-161 For use in Turkey L04544-141

For use in the Netherlands L04544-B31 For use in the United Kingdom L04544-031

For use in Portugal L04544-131 For use in the United States L04544-001

In dark ash silver nish: For use in Russia L04543-251

For use in Canada L04543-DB1 For use in Saudi Arabia L04543-171

For use in the Czech Republic

and Slovakia

L04543-FL1 For use in South Korea L04543-AD1

For use in Denmark, Finland,

and Norway

L04543-DH1 For use in Spain L04543-071

For use in France L04543-051 For use in Switzerland L04543-BG1

For use in Germany L04543-041 For use in Taiwan L04543-AB1

For use in Japan L04543-291 For use in Thailand L04543-281

Component replacement procedures 45

Questions and Answers:

Need help?

Do you have a question about the HP Spectre 13 and is the answer not in the manual?

HP Spectre 13 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Silver
Housing material	Aluminium, Carbon fibre
Country of origin	China
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	1866 MHz
Memory form factor	On-board
Internal memory type	LPDDR3-SDRAM
Memory layout (slots x size)	1 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
SSD form factor	M.2
Card reader integrated	No
Total storage capacity	1024 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
LED backlight	Yes
Display surface	Gloss
Display diagonal	13.3 \
Native aspect ratio	16:9
On-board graphics card ID	0x5916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 620
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	32 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Speakers manufacturer	Bang & Olufsen
Number of built-in speakers	2
WWAN	Not installed
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB Sleep-and-Charge ports	3
Cable lock slot type	Kensington
AC adapter power	45 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	19 V
Battery capacity	38 Wh
Battery life (max)	8 h
Number of battery cells	4
Pointing device	Touchpad
Bus type	OPI
Stepping	H0
Tjunction	100 °C
Processor cache	4 MB
Processor model	i7-7500U
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor socket	BGA 1356
Processor codename	Kaby Lake
Configurable TDP-up	25 W
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.9 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR
Processor code	SR2ZV
Processor ARK ID	95451
Processor package size	42 x 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
