HP Spectre 13 User Manual

1 Product description
Category Description
Product Name HP Spectre 13 Laptop PC (model number 13-af0xx)
Processors Intel® Core™ i7-8550U 1.80-GHz (turbo up to 4.00-GHz) quad core processor (2133-MHz, 8.0-MB L3 cache, 15-
W)
Intel Core i5-8250U 1.60-GHz (turbo up to 3.40-GHz) quad core processor (2133-MHz, 6.0-MB L3 cache, 15-W
Chipset Integrated soldered-on-circuit (SoC)
Graphics Internal graphics: Intel ultra high-denition (UHD) Graphics 620 graphics subsystem with universal memory
architecture (UMA) video memory
Support for DX12, high-denition multimedia interface (HDMI), and HD decode
Panel 13.3-in, UHD, white light-emitting (WLED), BrightView (3840×2160), uslim-at (2.0-mm), UWVA, eDP+PSR, 340
nits, 16:9 ultra wide aspect ratio, narrow bezel, TouchScreen display assembly with ush glass, multitouch
enabled, MSFT HDR streaming capable
13.3-in, full high-denition (FHD), WLED, BrightView (1920×1080), uslim-III-at (2.0-mm), UWVA, eDP+PSR, 300
nits, 16:9 ultra wide aspect ratio, narrow bezel, TouchScreen display assembly with ush glass, multitouch
enabled, MSFT HDR streaming capable
Memory System memory built into system board
Support for LPDDR3-2133 dual channel system memory
Support for up to 16-GB of system memory in the following congurations:
16384-MB (16384-MB (256-MB × 32 × 4 × 4 pieces)
8192-MB (256-MB × 16 × 4 × 4 pieces)
Storage Support for the following solid-state drives:
●
1-TB, M.2 2280-SATA-3/DS, PCIe, NVMe, solid-state drive with triple level cell (TLC)
●
512-GB, M.2 2280-SATA-3/DS, PCIe, NVMe, solid-state drive with TLC
●
360-GB, M.2 2280-SATA-3/DS, PCIe, NVMe, solid-state drive with TLC
●
256-GB, M.2 2280-SATA-3/DS, PCIe, NVMe, solid-state drive with TLC
●
128-GB, M.2 2280-SATA-3/DS, PCIe, NVMe, solid-state drive with TLC
Audio and video Audio:
Bang & Olufsen
Support for dual speakers
Support for HP Audio Boost 2.0 (with discrete amplier)
Camera:
HP Wide Vision HD infrared camera with indicator light, 2 infrared lights, USB 2.0, HD BSI sensor and infrared
sensor, f2.2, WDR, 88° WFOV, 720p by 30 frames per second
HP Wide Vision HD camera with indicator light, USB 2.0, HD BSI sensor, f2.2, WDR, 88° WFOV, 720p by 30 frames
per second
Microphones: Dual array digital microphones with appropriate beam-forming, echo-cancellation, noise-
suppression software
1

HP Spectre 13 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Silver
Housing material	Aluminium, Carbon fibre
Country of origin	China
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory clock speed	1866 MHz
Memory form factor	On-board
Internal memory type	LPDDR3-SDRAM
Memory layout (slots x size)	1 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
SSD form factor	M.2
Card reader integrated	No
Total storage capacity	1024 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
LED backlight	Yes
Display surface	Gloss
Display diagonal	13.3 \
Native aspect ratio	16:9
On-board graphics card ID	0x5916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 620
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	32 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Speakers manufacturer	Bang & Olufsen
Number of built-in speakers	2
WWAN	Not installed
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB Sleep-and-Charge ports	3
Cable lock slot type	Kensington
AC adapter power	45 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	19 V
Battery capacity	38 Wh
Battery life (max)	8 h
Number of battery cells	4
Pointing device	Touchpad
Bus type	OPI
Stepping	H0
Tjunction	100 °C
Processor cache	4 MB
Processor model	i7-7500U
System bus rate	4 GT/s
Processor family	Intel® Core™ i7
Processor socket	BGA 1356
Processor codename	Kaby Lake
Configurable TDP-up	25 W
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.9 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR
Processor code	SR2ZV
Processor ARK ID	95451
Processor package size	42 x 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	229 mm
Width	325 mm
Height	10.4 mm
Weight	1110 g
