A Specifications
MetricS.A.E.Specification
Dimensions:
13.2 cm5.2 inHeight
58.4 cm23.0 inDepth
42.7 cm16.8 inWidth
12.3 kg27 lbWeight (1 drive installed)
Input power requirements
90 to 264 VAC90 to 264 VAC
3.1 A 47 - 63 Hz3.1 A 47 - 63 Hz
140 W*140 W*
478 BTU/hr*478 BTU/hr*Heat Dissipation (max)
Temperature range
5° to 35° C41° to 95° FOperating
-40° to 66° C-40° to 150° FNon-operating
Relative humidity
20% to 80%20% to 80%Operating (non-condensing)
10% to 95%10% to 95%Non-operating
26° C79° FWet bulb temperature (max)
Altitude (max)
0 to 4000 m0 to 13,000 ftOperating
0 to 15200 m0 to 50,000 ftNon-operating
* Input power and Heat dissipation specifications are maximum values and apply to worst-case conditions at full rated
power supply load. The power/heat dissipation for your installation will vary depending on the equipment configuration.
23
