HP t510 User Manual

Windows Logo Key
Use the Windows Logo Key in combination with other keys to perform certain functions available in
Windows operating systems.
Windows Logo Key + Tab Switch between open items.
Windows Logo Key + e Open My Computer.
Windows Logo Key + f Search for a file or folder.
Windows Logo Key + Ctrl + f Search for computers.
Windows Logo Key + m Minimize all windows.
Windows Logo Key + Shift + m Undo minimize all.
Windows Logo Key + Break Display the System Properties dialog box.
Windows Logo Key + r Open the Run dialog box.
Additional Function Keys
The following key combinations also work on all thin clients regardless of operating system:
Alt + Esc Cycles through minimized applications.
Alt + Tab Cycles through open applications.
Alt + Shift + Tab Switches to the previous session.
Special Mouse Functions
Most software applications support the use of a mouse. The functions assigned to each mouse button
depend on the software applications you are using.
8 Chapter 1 Product Features

HP t510 Specifications

General

Processor cores	2
Processor model	U4200
Processor family	VIA Eden
Motherboard chipset	VIA VX900
Processor frequency	1 GHz
Storage media	Flash
Card reader integrated	No
Total storage capacity	1 GB
Internal memory	2 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Graphics card	Chromotion HD 2.0
Networking features	Gigabit Ethernet
Graphics card family	VIA
Dimensions (W x D x H) with stand	58.4 x 215.9 x 219.7 mm
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Operating system installed	-
Power supply	65 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Audio system	24-bit
Sustainability certificates	ENERGY STAR
Product color	Black
Country of origin	China

Weight and Dimensions

Depth	215.9 mm
Width	58.4 mm
Height	209 mm
Weight	1490 g
