HP t510 User Manual

If you install a USB mouse and a USB keyboard in the secure USB compartment, route the cables
around and through the clips, then out the secure cable routing slot, as shown in the following
illustration.
Figure 2-7 Using the secure cable routing slot
Removing and Replacing the Battery
Before beginning the replacement process, review General Hardware Installation Sequence
on page 10 for procedures you should follow before and after installing or replacing hardware.
WARNING! Before removing the side access panel, ensure that the thin client is turned off and the
power cord is disconnected from the electrical outlet.
To remove and replace the battery:
1. Locate the battery on the system board.
16 Chapter 2 Hardware Changes

HP t510 Specifications

General

Processor cores	2
Processor model	U4200
Processor family	VIA Eden
Motherboard chipset	VIA VX900
Processor frequency	1 GHz
Storage media	Flash
Card reader integrated	No
Total storage capacity	1 GB
Internal memory	2 GB
Memory clock speed	1066 MHz
Internal memory type	DDR3-SDRAM
Graphics card	Chromotion HD 2.0
Networking features	Gigabit Ethernet
Graphics card family	VIA
Dimensions (W x D x H) with stand	58.4 x 215.9 x 219.7 mm
Wi-Fi	Yes
Wi-Fi standards	802.11a, 802.11b, 802.11g
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	6
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Operating system installed	-
Power supply	65 W
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Audio system	24-bit
Sustainability certificates	ENERGY STAR
Product color	Black
Country of origin	China

Weight and Dimensions

Depth	215.9 mm
Width	58.4 mm
Height	209 mm
Weight	1490 g
