Table 3-1 Computer major component descriptions and part numbers (continued)
Item Component Spare part number
Fans, 80 W
(19a) Left M54776-001
(19b) Right M54776-001
(20) Heat sink, 80 W
NOTE: Thermal gel is available as spare part number M54780-001. Thermal grease is available as
spare part number M54779-001.
M54774-001
Fans, 60 W
(21a) Left M54775-001
(21b) Right M54775-001
(22) Heat sink, 60 W
NOTE: Thermal gel is available as spare part number M54780-001. Thermal grease is available as
spare part number M54779-001.
60 W (models with NVIDIA graphics) M54773-001
60 W (models with AMD Radeon RX 5500M graphics) M84787-001
Display assembly subcomponents
To identify the display assembly subcomponents, use this illustration and table.
Display assembly subcomponents 21
