AP4050DN-HD
Hardware Installation and Maintenance Guide 2 AP Installation
Issue 01 (2016-04-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10
Install the AP in a site that is free from leaking or dripping water, heavy dew, and
humidity, and take protective measures to prevent water from flowing into the equipment
along the cable.
Do not install the AP in an environment with high temperature, dust, poisonous gases,
flammable or explosive objects, electromagnetic interference (from a radar station, radio
station, or substation), unstable voltage, violent shakes, or strong noise.
Table 2-2 General anti-interference requirements
Scenario Deployment Distance Requirement
Indoor
installation
There should be at least a 7 m distance between antennas.
The antennas should be placed at least 2 m from the 4G antennas of
the carrier.
The antennas should be placed far away from electronic devices that
may produce interference, such as microwave ovens.
If antennas are embedded into APs, the deployment distance requirements on the antennas are those on
APs.
2.5 Installing the AP
Remove the protective film on the surface before installation to prevent electrostatic discharge.
2.5.1 Installing the Device on a Wall
Mounting kits and expansion bolts are required to install the AP on a wall. The
AP4050DN-HD can be installed on a wall using an indoor fixed or angle-adjustable mounting
bracket.
The indoor fixed mounting bracket is delivered together with the AP, but the angle-adjustable mounting
bracket is optional and needs to be purchased separately.
Indoor Fixed Mounting Bracket
1. Fix the mounting bracket to the wall, adjust the installation position, and use the marker
to mark the drilling positions where expansion screws are installed.
