User Manual
EchoLife HG520 Home Gateway
Chapter 5 Advanced Setup
Huawei Technologies Proprietary
50
Note:
If changing the “Enable Automatic Assigned Default Gateway” from
unselected to selected, you must reboot HG520 to activate the
automatic assigned default gateway.
5.6.2 Static Route Configuration
1)
Click on <Add> to cr
eate a new Static Route up to 32 entries can be configured.
Figure 5-16 Advanced Setup – Routing – Static Route
2) Enter the destination network address, subnet mask,
gateway AND/OR available WAN interface, and then click
<Apply> to add the entry to the routing table.
