Huawei FusionModule5000 Product Description

FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
68
Item
Specifications
Power input
⚫
Supports two AC inputs
⚫
Rated voltage; 200–240 V AC/100–120 V AC
⚫
rated frequency; 50 Hz/60 Hz
⚫
Input current; 6.7 A
Power output
⚫
rated voltage: 53.5 V DC
⚫
Output power of two power supplies: 2000 W (176–300 V AC);
940 W (linear derating at 85–175 V AC)
⚫
Output power of a single power supply: 1000 W (176–300 V
AC); 470 W (linear derating at 85–175 V AC)
⚫
Output current: 14 A
System memory
512 MB
Solid state disk
2 GB and 128 MB of storage space
FE port expansion
Supports two WAN ports, two LAN ports, and 10/100M
communications rate
RS485 serial port
expansion
⚫
Four RS485 ports with the default communications rate of 9600
bit/s
⚫
Each port provides 12 V DC power with the rated current of 450
mA.
AI/DI expansion
(RJ45)
⚫
Supports six AI/DI ports to connect to smoke sensors, water
sensors, and temperature sensors.
⚫
Each port provides 12 V DC power with the rated current of 85
mA.
DO expansion
(RJ45)
⚫
Supports two expansion dry contacts with contact point capacity
of 20 W, maximum withstand voltage of 60 V DC, and rated
current of 0.5 A.
⚫
Supports the active DO port with an output voltage of 12 V DC
and output current of 450 mA.
Wireless
communication
Supports wireless communication that complies with
IEEE802.15.4.
3G
Supports 3G (WCDMA) communication and is compatible with 2G
(GSM) communication. A standard SIM card slot is provided.
NOTE
The prerequisite for using a SIM card is that the site has signal coverage.
USB
Provides a general USB port.
Button
⚫
SW: wireless network pairing button
⚫
Default: restores the default IP address
