NOTE
On one device, only oneAuxiliary Flexible Interface Card with 4-Port 100Base-RJ45(FIC, Supporting
1588v2) can be housed.
The Auxiliary Flexible Interface Card with 4-Port 100Base-RJ45(FIC, Supporting 1588v2)
consists of the service access module, auxiliary interface module, control drive module, clock
module, and power module.
l Service access module
– Inputs 4-channel FE electrical signals.
– Implements physical-layer interface functions and supports Medium Access Control
(MAC) address-based communications.
– Supports the signal cache function to prevent FE signal loss.
– Supports the flow control function to control the packet volume.
– Processes IEEE 1588v2 packets.
l Auxiliary interface module
– Provides 4-channel alarm input interfaces.
l Control drive module
– Detects the system status through the management and control bus.
– Processes alarm signals, orderwire signals, and transparent data signals.
– Supports hot swapping.
l Clock module
– Provides clock signals for service access and convergence module.
– Provides clock signals for the auxiliary interface module.
– Supports synchronous Ethernet and the Synchronization Status Message (SSM)
protocol.
– Supports IEEE 1588v2.
l Power module
– Inputs 2-channel -48 V/-60 V DC power.
– Supplies 3.3 V or 1.2 V power.
Table 3-32 Description of the interfaces on the Auxiliary Flexible Interface Card with 4-Port
100Base-RJ45(FIC, Supporting 1588v2)
Interface
Type Description
F1 RJ-45 Reserved
PHONE RJ-45 Reserved
ALMO RJ-45 Reserved
ALMI RJ-45 Interface that inputs four
channels of alarm signals
FE0-FE3 RJ-45 Interfaces that input and
output FE electrical signals
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description 3 Boards
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
65
