17
2. On the login page, enter the login user name (admin by default) and password (admin
by default). Click Login.
To protect against unauthorized access, change the user name and password after the first
login.
3. In the navigation tree, choose SETUP > Internet Setup.
4. In Connection Type, choose the connection type based on the application scenario.
Application Scenario Connection Type
The user name and password are provided by your service
provider.
PPPoE
Certain parameters, such as the static IP address and DNS
server address, are provided by your service provider.
Static IP
No parameters are provided by your service provider. The
IP address is automatically assigned by the service
provider.
Dynamic IP
5. Select LAN2/WAN for WAN port.
6. Configure the PT530's Internet parameters.
ā If you choose PPPoE or Static IP, enter the parameters provided by your service
provider, and click Apply.
