NOTICE:
• The diameter of a pole for installing an RRU ranges from 60 mm (2.36 in.) to 114 mm (4.49 in.).
The recommended diameter is 80 mm (3.15 in.).
• The recommended thickness of the pole wall is 3.5 mm (0.14 in.) or above.
• When RRUs are installed on a pole, the side-mounted installation is recommended. A maximum
of three RRUs can be installed on a pole with the diameter ranging from 60 mm (2.36 in.) to 76
mm (2.99 in.).
• Only a pole whose diameter ranges from 76 mm (2.99 in.) to 114 mm (4.49 in.) supports more
than three RRUs.
Figure 4 shows a single RRU installed on a pole.
Figure 4 A single RRU installation on a pole
Figure 5 shows two RRUs installed on a pole.
