2 Product Overview
2.1 Model Description
Figure 2-1 Top air-ow cabinet model number
Table 2-1 Model number description for the top air-ow cabinet
No.
Description
1 Accessory
2 Top air-ow cabinet
3 ● 00: used for 600 mm wide cabinets, with a fan transit unit
● 01: used for 600 mm wide cabinets
● 02: used for 800 mm wide cabinets
● Single-cabinet UPS: The UPS has only one cabinet. The following gure shows
the installation position for the top air-ow cabinet.
UPS5000 Top Air-ow Cabinet
User Manual 2 Product Overview
Issue 02 (2022-01-19) Copyright © Huawei Technologies Co., Ltd. 2
