On Screen Display (OSD) (Continued) __________________
Color Option
Field
Options Include
Default
Color
Auto
R. Gain
-7 – +7
0
G. Gain
-7 – +7
0
B. Gain
-7 – +7
0
Saturation
0 – 14
7
Hue
0 – 14
7
ATW
R. Gain
-7 – +7
0
G. Gain
-7 – +7
0
B. Gain
-7 – +7
0
Saturation
0 – 14
7
Hue
0 – 14
7
One Push
One Push Trigger
Press OK
Press OK
Saturation
0 – 14
7
Hue
0 – 14
7
Indoor
Saturation
0 – 14
7
Hue
0 – 14
7
Outdoor
Saturation
0 – 14
7
Hue
0 – 14
7
Manual
R. Gain
0 – 255
128
B. Gain
0 – 255
128
Saturation
0 – 14
7
Hue
0 – 14
7
Sodium Lamp
Saturation
0 – 14
7
Hue
0 – 14
7
Fluo Lamp
Saturation
0 – 14
7
Hue
0 – 14
7
Field
Options Include
Default
Pan Tilt Zoom
Pan/Tilt Speed
1 – 8
5
D-Zoom Limit
X1 – X11
X1
PTZ Trig AF
OFF, ON
ON
Ratio Speed
OFF, ON
ON
Power Up Act
HOME, PRESET1 – PRESET9
HOME
Field
Options Include
Default
System
Address
1 – 7
1
Protocol
VISCA, PELCO-D, PELCO-P
VISCA
Baudrate
2400, 4800, 9600, 38400
9600
IR Address
1 – 4
1
Video Format
720P60, 720P50, 1080P60, 1080P50,
1080P30, 1080P25, 1080I60, 1080I50
1080P30
Mount Mode
Stand, Ceiling
Stand
RS485 Port
HALF-DUPLEX-1, HALF-DUPLEX-2
HALF-DUPLEX-1
Language
English, Chinese
English
