Hunter XC User Manual

TROUBLEsHOOTInG GUIDE (cont.)
PROBLEM CAUSES SOLUTIONS
Display shows a station is running but the
and icons are flashing.
Thesensoris interrupting irrigation, however
the station has been programmed to
override the sensor.
Check the sensor override status (see page 10).
Automatic irrigation does not start at the
start time and controller is not in the
System Off mode.
AM/PM of time of day not set correctly.
AM/PM of start time not set correctly.
Start Time is disabled (set for Off).
Controller is not receiving AC power.
Correct AM/PM of time of day.
Correct AM/PM of start time.
See Setting Start Times (pg 7).
Check AC power connections.
sPECIFICATIOns
Operating Specifications Electrical Specifications
•
Station Run Times: 0 to 4 hours in 1
-
minute
•
Transformer input 120VAC ±10% 60 Hz
increments.
(230VAC ±10% 50/60 Hz International
• 3 Independent Watering Programs. Models).
•
Transformer Output: 24VAC 1.0 amp.
•
Start Times: 4 per day per program for
up to 12 daily starts. • Station Output: .56 amps per station.
• Watering Schedule: 365-day calendar, • Maximum Output: .84 amps
interval watering, odd/even watering. (includes master valve).
• AM/PM, 24-hour clock. • Battery: 3V Lithium (included) used for re-
• Simple manual operation. mote programming and backup timekeep-
ing. Use CR2032 3
-
volt.
•
Sensor override by station.
•
Electronic short circuit protection.
•
Programmable rain delay (1 to 7 days).
•
Non
-
volatile memory for program data.
•
Seasonal adjustment (10% to 150%).
•
UL Listed.
•
Sensor bypass switch.
•
Model XC
-
x00 has an IP24 Rating for
•
XC
-
x00i for indoor use. XC
-
x00 for
Pollution Degree 4.
outdoor use.
•
Clean only with a cloth dampened with
•
Sea level to 2000m at 0
-
50°C.
mild soap and water.
Explanation of Symbols
= AC
= Consult Documentation
= Hazardous Voltages Present =
Ground
