14 – English
6004-009Hy
6017-214
PRESENTATION
Lift lever for cutting unit
The lift lever is used to set the cutting unit in trans-
port or cutting position.
If the lever is pulled back the unit will lift up and the
blades will automatically stop rotating (transport
position).
If the lock button is pressed and the lever is moved
forward the unit will be lowered and the blades will
automatically start rotating (cutting position).
The lever can also be used to temporarily regulate
the cutting height, e.g. for a small mound in the lawn.
Cutting unit
Rider 11 and Rider 13 have a cutting unit with rear
ejection, i.e. the grass cuttings are thrown out
behind the cutting unit.
Rider 11 Bio and Rider 13 Bio have a twin-blade
BioClip cutting unit.
6004-012H
6004-011H
Lifting of the cutting unit (transport position)
Lowering of the cutting unit (cutting position)
