English – 15
Rider 13 H
6004-013H
6004-014
6004-015
PRESENTATION
Lever for adjustment of cutting height
With this lever the cutting height can be adjusted to
9 different positions.
Cutting unit with rear ejection, 40-90 mm
(1 9/16" - 3 9/16")
BioClip cutting unit, 45-95 mm
(1 3/4" - 3 3/4")
Seat
The seat has a jointed attachment on the front
edge and can be tipped forward.
The seat can also be adjusted lengthways.
Release the knobs under the seat and adjust it
forwards or backwards to the required position.
Lock the adjustment with the wheels.
WARNING!
Petrol/gasoline is highly
inflammable. Observe care and
fill up with fuel outdoors
(see safety instructions).
Fuelling
The engine should be run on 85 octane unleaded
petrol/gasoline (no added oil). Environmentally
adapted alkylate fuel is also recommended.
Do not use petrol that contains methanol.
Do not fill the tank completely, leave an expansion
area of at least 2.5 cm (1").
