114242 5-5 REV B
Engine RPM Settings
The engine rpm’s are set at the factory for maximum mowing efficiency. Occasionally it may be necessary to check and adjust the
settings. The idle speeds should be set as follows:
NOTE: Model numbers may or may not end with an extension after the number. There are several different extensions that may be
shown; i.e. EX, AU or CE.
Example: 922222 (no extension)
922222 EX
922222 CE
922222 US
922222 AU
Kawasaki FX691 / FX730
ENGINE SPEED
MODEL NO. ENDING WITH: HIGH IDLE
MODEL NO. WITHOUT EXTENSION
MODEL NO. WITH EX EXTENSION
MODEL NO. WITH US EXTENSION
3600 ± 50 RPM
Honda GXV630
ENGINE SPEEDS
MODEL NO. ENDING WITH: LOW IDLE HIGH IDLE
MODEL NO. WITH EX EXTENSION
MODEL NO. WITH US EXTENSION
1900 ± 100 RPM 3600 ± 50 RPM
MODEL NO. WITH CE EXTENSION 1900 ± 100 RPM 2900 ± 50 RPM
