REV B 6-6 114242
60" Deck Belt Routing & Tensioning
48" Rear Discharge Deck Belt Routing & Tensioning
Figure 6-15
8.3” – 9.3”
(210.8mm – 236.2mm)
48” Rear discharge deck
available as a CE mower only.
48” Rear discharge deck
available as a CE mower only.
48” Rear discharge deck
available as a CE mower and as
an EX mower for Canada only.
Figure 6-16
8.3” – 9.3”
(210.8 – 236.2mm)
8.3” – 9.3”
(210.8 – 236.2mm)
8.3” – 9.3”
8.3” – 9.3”
(210.8 – 236.2mm)
