EDS 3000 Operating Manual
PN#02080105 • ELC1603-1752 / 09.16
ELECTRONICS
10. Technical Data
10.1 EDS 3000 w/ Ceramic Sensor Cell;
Absolute and Relative Pressure ≤ 500 psi
Input Data:
Measuring Ranges
Ceramic sensors absolute pressure
15,50 psi
Overload pressures 45,150 psi
Burst pressure 70, 250 psi
Measuring ranges
Ceramic sensors relative pressure
-14.5 to 75, 15, 30, 50, 150, 250, 500 psi
Overload pressures 290, 45, 100, 150, 450, 725, 1500 psi
Burst pressure 400, 70, 150,250, 650, 1000, 2500 psi
Mechanical connection 1/4”-18 NPT male
Torque value 30 lb-ft (40 Nm)
Parts in contact with medium Mech. connection: Stainless steel
Sensor cell: Ceramic
Seal: FPM / EPDM (as pre model code)
Output Data:
Accuracy to DIN 16086, ≤ ± 0.5 % FS typ.
Max. setting (display, analog output) ≤ ± 1 % FS typ.
Repeatability ≤ ± 0.25 % FS max
Temperature drift ≤ ± 0.014 % FS / ºF max. zero point
≤ ± 0.014 % FS / ºF max. range
Analog Output (optional)
Signal selectable:
4 .. 20mA ohmic resistance max 500Ω
0 .. 10 V ohmic resistance min. 1 kΩ
Switching outputs
Type PNP transistor output
Switching current max. 1.2 A
Switching cycles > 100 million
Reaction time < 10 ms
Long-term drift ≤ ± 0.3 % FS typ. / year
