EDS 3000 Operating Manual
PN#02080105 • ELC1603-1752 / 09.16
ELECTRONICS
11.2 EDS 3000 with thin film DMS sensor cell;
relative pressure ≥1000 psi
EDS 3 X X X - X - XXXX - 400
Model (Technology)
4 = thin film DMS, relative
Mechanical Connection
7 = SAE-6 male thread (9/16-18 UNF2A)
Note: G 1/4 port sizes are available upon request
Electrical Connection
6 = 4-pole plug, M12x1
(only available for output models 1, 2 & 3
connector not included)
8 = 5-pole plug, M12x1
(only available for output model 5
connector not included)
Output
1 = 1 switching output
(only in conjunction with electrical
connection type 6)
2 = 2 switching outputs
(only in conjunction with electrical
connection type 6)
3 = 1 switching output and 1 analog output
(only in conjunction with electrical
connection type 6)
5 = 2 switching outputs and 1 analog output
(only in conjunction with electrical
connection type 8)
Pressure Ranges - psi (bar versions available)
1000; 3000; 6000; 9000
Modification Number
400 = standard (determined by the manufacturer)
