EDS 3000 Operating Manual
PN#02080105 • ELC1603-1752 / 09.16
ELECTRONICS
11. Model codes (also order codes)
11.1 EDS 3000 with ceramic sensor cell;
absolute and relative pressure ≤500 psi
EDS 3 X X X - X - XXXX - 400 - X X
Model (Technology)
1 = ceramic absolute
3 = ceramic relative
Mechanical Connection
8 = 1/4” - 18 NPT male thread
Note: G 1/4 port sizes are available upon request
Electrical Connection
6 = 4-pole plug, M12x1
(only available for output models 1, 2 & 3,
connector not included)
8 = 5-pole plug, M12x1,
(only available for output model 5,
connector not included)
Output
1 = 1 switching output
(only in conjunction with electrical
connection type 6)
2 = 2 switching outputs
(only in conjunction with electrical
connection type 6)
3 = 1 switching output and 1 Analog output
(only in conjunction with electrical
connection type 6)
5 = 2 switching outputs and 1 Analog output
(only in conjunction with electrical
connection type 8)
Pressure Ranges (psi)(bar versions available)
Type 1 (ceramic absolute)
0015; 0050
Type 3 (ceramic relative)
0015; 0030; 0050; 0150; 0250; 0500; 0089 (-14 to 75)
Modification Number
400 = standard (determined by the manufacturer)
Seal Material (in contact with medium)
F = FPM seal (e.g. for hydraulic oils)
E = EPDM seal (e.g. for water, coolants)
Connection Material (in contact with medium)
1 = stainless steel
