EDS 3000 Operating Manual
PN#02080105 • ELC1603-1752 / 09.16
ELECTRONICS
Ambient condition
Compensated temperature range -14 .. +158º F
Operating temperature range -13 .. +176º F (-13 .. +140º F acc. to UL)
Storage temperature range -40 .. +176º F
Fluid temperature range -13 .. +176º F
mark
EN 61000-6-1 / 2 / 3 / 4
* mark
certicate No. E318391
Vibration resistance to
DIN EN 60068-2-6 at 10 .. 500 Hz
≤ 10 g
Shock resistance to
DIN EN 60068-2-29 (11 ms)
≤ 50 g
Protection class to IEC 60529 IP 67
Other Data
Supply voltage 9 .. 35 V DC without analog output
18 .. 35 V DC with analog output
when using acc.to UL-specication - limited energy -
9.3 UL 61010; Class 2;
UL 1310/1585; LPS UL 60950
Current consumption max. 2,455 A total
max. 35 mA with inactive switching outputs
max. 55 mA with inactive switching outputs
and analog output
Display 4-digit, LED, 7 segment, red,
height of digits 7 mm
Weight approx. 120g
Note:
Reverse polarity protection of the supply
voltage, excess voltage, override, short
circuit protection are provided.
FS (Full Scale) = relative to the complete
measuring range
*Envir. conditions to 1.4.2 UL 61010-1; C22.2
No 61010-1

Hydac EDS 3000 Specifications

General

Brand	Hydac
Model	EDS 3000
Category	Switch
Language	English
