PARTS LIST
HySpeed HT2000 Instruction Manual 9-9
20
HT2000 Power Supply : Center Wall Right Side
Part
Item Number Description Designator Qty.
1 001230 Panel, MAX200 Center 1
2 029359* Linkboard SA, MAX200 240-480V 1
3 003138 Circuit Breaker, 2 Pole, 600V 20A CB1 1
4 003139 Contactor:90A 3P 120VAC CON1 1
029316† Incoming Power TB1 SA, MAX200 TB1 1
5 004290 Rail, 400E TB12/200 TB1 1
6 008358 Terminal Block 1
7 008485 Terminal Block 3
8 008295 Holder, E/UK Term Blk End 1
9 029318* Cont Transf'mer SA 240-480/3PH/60 T1 1
9 029441** Cont Transf'mer SA 208/3/60 T1 1
9 029362*** Cont Transf'mer SA 220-380-400-415/50 T1 1
9 029422**** Cont Transf'mer SA 200V/3PH/50Hz T1 1
9 029404***** Cont Transf'mer SA 600/3/60 T1 1
9 029713****** Cont Transf'mer SA 440-460/3/50-60 T1 1
10 008481 Grommet Strip. Panel 18"
11 041534†† PC BD Assy, Power Distribution PCB1 1
12 003142 Relay, 120 VAC DPDT CRA 1
13 003142 Relay, 120 VAC DPDT CRB 1
001601††† Plate:CE/LVD Lift Eye 1
001602††† Gasket:CE/LVD Lift Eye 1
* Used on 240/480 volt power supplies
** Used on 208 volt power supplies
*** Used on 220/380/415 volt power supplies and 400V CE power supplies
**** Used on 200 volt power supply
***** Used on 600 volt power supplies
****** Used on 440/460V power supplies
† See Appendix E for location of 029316 on 400V CE power supplies.
†† See Figure 8-2 for front graphic of 041534 power distribution board.
††† Not shown graphically in Figure 9-4.
