5-8
4. SEAT ADJUSTMENT
Forward/Backward adjustment(A)
Pull lever A to adjust seat forward or back ward.
The seat can be moved forward and backward over 156
mm
in
12 steps.
Reclining adjustment(B)
Pull lever B to adjustment seat back rest.
The backrest of the seat can be reclined to 31Ü2
Á
forward and
34.6Ü2
Á
backward.
CCushion adjustment (C)
Adjusting handle to the operator's weight.
The suspension stroke is 20
mm
upward and downward
respectively.
SEAT ADJUSTMENT
1)
BUCKLING UP
2)
Buckling up. Be sure that you put on the seat belt. Connect
and adjust the seat belt strap to a snug, comfortable position.
Always wear your seat belt when operating a lift truck.
Failure to wear seat belt will result in injury or death in an
event of an accident.
(1)
L255OM119
The seat adjustable to fit the contours of the operator's body. It will reduce operator fatigue due to long
works hours and enhance work efficiency.
(1)
(2)
Η
Θ
