1. RATCHET TYPE PARKING LEVER
Put the lever in the brake released position.
Tighten it with a adjust screw so that lever
stroke is 12.1
ä
.
1)
2)
Â15D/18D/20DA-7E, 20D/25D/30D/33D-7E, 20DF/25DF/30DF/33DF-7, 35DF-7
IIt should be maintained at least 4 mm of
the latching depth that the pawl of the
parking lever is haspe
d on the latch of
the cowl so that it can prevent the
parking brake from unexpected releasing
problem of
the parking operation.
ö
Put the lever to the brake released position.
Pull the parking lever up to the specified
stroke which is 23
Á
for 35D/40D/45D-7E,
50D-7AE, 50DF/60DF/70DF-7 and 26
Á
for
50D/60D/70D-7E, 80D-7E respectively and
the fix the adjust nut.
1)
2)
ÂÂ35D/40D/45D-7E, 50DA-7E, 50D/60D/70D-7E, 50DF/60DF/70DF-7
50DF7OM98
