9- 16 DO-IT-YOURSELF MAINTENANCE
!
CAUTION:
When replacing a fusible link, never
use anything but a new fusible link
with the same or lower amperage
rating. Never use a piece of wire or
a higher-rated fusible link. This
could result in serious damage and
create a fire hazard.
G200B02A-AAT
Replacing Accessory Fuse
The fuse box for the lights and other
electrical accessories will be found low
on the dashboard on the driver's side.
Inside the box you will find a list show-
ing the circuits protected by each fuse.
If any of your car's lights or other elec-
trical accessories stop working, a blown
fuse could be the reason. If the fuse has
burned out, you will see that the metal
strip inside the fuse has burned through.
If you suspect a blown fuse, follow this
procedure:
1. Turn off the ignition and all other
switches.
2. Open the fuse box and examine
each fuse. Remove each fuse by
pulling it toward you (a small "fuse
puller" tool is contained in the fuse
box to simplify this operation).
3. Be sure to check all other fuses even
if you find one that appears to have
burned out.
G200A01A-AAT
CHECKING AND REPLACING
FUSES
Replacing a Fusible Link
Melted
Good
A fusible link will melt if the electrical
circuits from the battery are ever over-
loaded, thus preventing damage to the
entire wiring harness. (This could be
caused by a short in the system draw-
ing too much current.) If this ever
happens, have a Hyundai dealer de-
termine the cause, repair the system
and replace the fusible link. The fusible
links are located in a fuse box for easy
inspection.
G200A01A
HLC4002-D
