FEATURES OF YOUR VEHICLE 4- 55
B710A01TB-DAT
HEATING AND COOLING CONTROL (If Installed)
1. Side defrost nozzle
2. Side Ventilator
3. Windshield Defrost Ventilator
4. Centre Ventilator
HLC003-E
1
2
3
4
1
2
B710B01S-DAT
CENTRE VENTILATOR
The centre ventilators are located in
the middle of the dashboard. The di-
rection of air flow from the vents in the
centre of the dashboard is adjustable.
To control the direction of the air flow,
move the knob in the centre of the vent
up-and-down and side-to-side.
B710C01HP-DAT
SIDE VENTILATOR
The side ventilators are located on
each side of dashboard. To change
the direction of the air flow, move the
knob in the centre of the vent up-and-
down and side-to-side. The side vent
knobs control the amount of outside air
entering the vehicle through the side
vents. The vents are opened when the
vent knob is moved to " " position.
The vents are closed when the vent
knob is moved to " ". Keep these
vents clear of any obstructions.
