The actual motor compartment in the vehicle may differ from the illustration.
ONE1091001
1. PE coolant reservoir ..............................9-12
2. HV battery coolant reservoir.................9-12
3. Brake fluid reservoir ..............................9-13
4. Windshield washer fluid reservoir ........9-14
5. Fuse box .................................................9-31
6. Cabin air filter ........................................9-15
7. Front trunk ............................................5-65
8. Battery (12 volt) ......................................9-19
