IBC AHU 800 User Manual

Slide out fan assembly
Flexible filter rack positioning
High efficiency fin tube coil
Multi-position configurations
Industry standard duct sizes – supply air opening compatible with cased and uncased A/C
and heat pump coils
Single stage or 2-stage heating and cooling, or 2-stage heat pump
Compact design for those awkward spaces; the ability to orient horizontally or vertically
Heat pump capable
Control for external pump (5A - 120V)
Flexible electrical connection knock-outs on left and right sides
Standard thermostat capable
WiFi connection for programming with the IBCconnect mobile app
Maximum return air temperature 122 °F (50 °C)
Sensors for protection and operation:
Included
Sensors for supply air, return air, supply water, return water, humidifier, de-
humidifier, and Cold Air Sentry
Available options
Outdoor sensor IBC part # P-9067
AC Freeze sensor IBC part # P-1015
1.2 Conformity
Installation must conform to the requirements of the authority having jurisdiction. In the absence of
such requirements, the installation must conform to the National Electrical Code ANSI/NFPA No.
70, current edition.
The air handling appliance water circuit is certified to meet the NSF lead-free standard.
18
Section: Introduction
